230VAC Input Voltage Air Ventilation Blowers , Ceiling Fan Motor Replacement

Place of Origin China
Brand Name Retek
Certification CE, CCC,UL
Model Number W10825
Minimum Order Quantity 1000pcs
Price $6.5
Delivery Time 45days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 50000pcs per month
Product Details
Input Voltage 230VAC Speeds Adjustable 5 Speeds Optional
Output Power 55W Control Method Remote Control And Manual Operation
Housing Die Casted Shaft SUS304/#45
Bearing Ball Bearing Standard UL Standard
Insulation Class F Shaft Diameter 12mm
High Light

standing fan motor

,

ceiling fan motor

Leave a Message
Product Description

230VAC Input Voltage Air Ventilation Blowers , Ceiling Fan Motor Replacement



AC Power Source EC Motor



BIG Advantages:



Low Noise: Negligible noise comparing to Brushed DC Motors

Durable Life: Long lifes over 20000hrs.

Energy Saving: comparing to PSC motors and induction motors over 30% energy saving

Direct Input: Connect with 230VAC Power Source directly



Product Information:



Model: W10825-230

Voltage: 230VAC/50Hz

Markets Covered: Middle East ,Southeast Aisa and Middle Asia



Typical Specification:



Input Voltage 230VAC
Speeds Adjustable 5 Speeds optional
Output Power 55W
Control Method Remote Control and Manual Operation
Housing Die Casted
Shaft SUS304/#45
Bearing Ball Bearing
Insulation Class F
Shaft Diameter 12mm
Standard UL Standard





Performance @230VAC/50Hz Input Power Source:



Model Speed
Switch
Performance
Voltage(V) Current(A) Power(W) Speed(RPM)
Ceiling Fan Motor
230VAC Version
1st. Speed 230VAC 0.204A 21.1W 234RPM
2nd. Speed 230VAC 0.276A 30W 265RPM
3rd Speed 230VAC 0.35A 34.7W 293RPM
4th. Speed 230VAC 0.407A 47.7W 315.6RPM
5th. Speed 230VAC 0.456A 54.3W 327RPM


230VAC Input Voltage Air Ventilation Blowers , Ceiling Fan Motor Replacement 0

230VAC Input Voltage Air Ventilation Blowers , Ceiling Fan Motor Replacement 1

230VAC Input Voltage Air Ventilation Blowers , Ceiling Fan Motor Replacement 2







FAQ

1. What are your prices?

Our prices are subject to specification depending on technical requirements. We will make offer we clearly understand your working condition and technical requirements.

2.Do you have a minimum order quantity?

Yes, we require all international orders to have an ongoing minimum order quantity. Normally 1000PCS, however we also accept the custom made order with smaller quantity with higher expense.

3.Can you supply the relevant documentation?

Yes, we can provide most documentation including Certificates of Analysis / Conformance; Insurance; Origin, and other export documents where required.

4.What is the average lead time?

For samples, the lead time is about 14 days. For mass production, the lead time is 30~45 days after receiving the deposit payment. The lead times become effective when (1) we have received your deposit, and (2) we have your final approval for your products. If our lead times do not work with your deadline, please go over your requirements with your sale. In all cases we will try to accommodate your needs. In most cases we are able to do so.

5.What kinds of payment methods do you accept?

You can make the payment to our bank account, Western Union or PayPal: 30% deposit in advance, 70% balance before shipment.
