3.3 Inch PSC Air Ventilation Blowers , Die Casted Replace Motor In Ceiling Fan

Place of Origin China
Brand Name Retek
Certification CE, CCC
Model Number W7020
Minimum Order Quantity 1000pcs
Price $8.5
Delivery Time 45days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 50000pcs per month
Product Details
Housing Die Casted Shaft SUS304/#45
Bearing Ball Bearing Standard UL Standard
Insulation Class F Shaft Diameter 12mm
Input Voltage 230VAC Output Power 35W
Speeds Adjustable 3 Speeds
High Light

standing fan motor

,

ceiling fan motor

Leave a Message
Product Description





Compact Blower Fan EC Motor



Advantages:

Lower Noise comparing to Brushed DC Motors

Long lifespan over 20000hrs.

High Efficiency comparing to PSC motors and induction motors

Connect with AC Power Source directly



Model: W7020-230

Voltage: 230VAC/50Hz

Markets Covered: Middle East ,Southeast Aisa and Middle Asia.



3.3 Inch PSC Air Ventilation Blowers , Die Casted Replace Motor In Ceiling Fan 0

3.3 Inch PSC Air Ventilation Blowers , Die Casted Replace Motor In Ceiling Fan 1

3.3 Inch PSC Air Ventilation Blowers , Die Casted Replace Motor In Ceiling Fan 2



Performance @230VAC/50Hz Input Power Source:



Model Speed
Switch
Performance
Voltage(V) Current(A) Power(W) Speed(RPM)
Wall Bracket Fan Motor
230VAC Version

1st. Speed 230VAC 0.13A 12.3W 899RPM
2nd. Speed 230VAC 0.205A 20.9W 1149RPM
3rd Speed 230VAC 0.315A 35W 1399RPM



Reference Outline:



3.3 Inch PSC Air Ventilation Blowers , Die Casted Replace Motor In Ceiling Fan 3



Manual Operation or Remote Control available.

Contact us today to custom design your desired motors.
