| Brand Name: | Retek |
| Model Number: | D82138A |
| MOQ: | 1000pcs |
| Price: | Negotiable |
| Delivery Time: | 14days |
The motor also adopts the skewed slots design which greatly improve the electromagnetic noise.
By using bonded epoxy, the motor can be used in very harsh circumstances with severe vibration such as ambulance ventilator pump, suction pump and etc. In medical field.
The magnets can be use NdFeB(Neodymium Ferrum Boron) or conventional ferrite materials.
82mm OD: D82 Series 82ZYT DC Motors for Grinders, Ice Augers,Spreaders, Saw, Automatic Doors,Actuators
Features:
Low Noise, Long lifespan, Cost less and Save more for your benefits.
Specification:
| Voltage Range: | 12VDC~220VDC |
| Power Power | 50W~300W |
| Number of Poles | 2/4 |
| Optional Motor Frame Diameter | 78mm, 80mm, 82mm and 83mm diameter |
| Optional shaft material | SS303, SS304, #45 Steel, Cr 40 |
| Frame diameter | 78mm, 80mm, 82mm |
| Insulation Grade | Class F |
| Rated Speed | 3000RPM~9000RPM |
| Optional housing surface treatment | Powder Coating, Electro phoresis surface treatment. |
| Magnet material | Hard Ferrit or rare earth |
| Armature Design | Skewed Slots Rotor Design for smooth running and low electro noise |
Typical Application:
Gearmotor, linear actuator,power tool, spreader,auger,automations and so on.
Drawing:
Typical Specification:
| Model | D78/D80/D82/D83 | |||
| Rated voltage | V dc | 12 | 24 | 48 |
| Rated speed | rpm | 2580 | 2580 | 2580 |
| Rated torque | N.m | 1 | 1 | 1 |
| Current | A | 32 | 16 | 9.5 |
| Starting torque | N.m | 5.9 | 5.9 | 5.9 |
| Starting current | A | 175 | 82 | 46 |
| No load speed | rpm | 3100 | 3100 | 3100 |
| No load current | A | 3 | 2.5 | 2 |
| Demag current | A | 250 | 160 | 90 |
| Rotor inertia | Gcm2 | 3000 | 3000 | 3000 |
| Weight of motor | kg | 2.5 | 2.5 | 2.5 |
| Motor length | mm | 140 | 140 | 140 |
Certificate:
Package:
Q1: What is our factory product range?
A: Stepper Motor, Brushless Motor, Servo Motor and AC Motor.etc
Q2: Can I get some samples?
A:We are honored to offer you samples for quality check.
Q3: Do you have the products in stock?
A:Our products are manufactured according to your order except the normal products.
Q4: What's the delivery time?
A:It usually takes about 14 working days,but the exact delivery time might be different for different order or at different time.
Q5: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the beginning to the end of the production. Every product will be fully assembled and carefully tested before packed.
Q6: What's your warranty terms?
A: We offer different warranty terms for different products. Please contact with us for details.
Q7:What information do you need if we need a recommendation on motor?
We need to know the basic specification of the motor:Dimesnion, Application, Voltage, Speed and Torque. If you have samples or drawing , it would be better you send us.In order to better provide you with the products you need.
Our advantage:
1. Our products have a competitive advantage.
2. We have a team of professional engineers to solve various technical problems and provide you with more professional advice.
3. Good working environment and corporate cohesion.
Our service:
1. Your inquiry about our products or prices will be answered within 24 hours.
2. Well-trained, experienced staff answer all your questions in fluent English.
3. Check the goods before shipment.
4. We respect your feedback after receiving the goods.
Our company is a manufacturing company specializing in the production of motors. If you have any needs, please contact us, we will protect your sales area, design concept and all private information.
The above motors are a small part of our products for your reference and viewing.
If you want to know more about the product, please contact us!
|
|
